SRIMAHAN | Power Plus Series

Power Plus Series

The Power Plus Series is a heavy-duty agricultural rotavator designed for high-performance tilling and land preparation. Available in 4Ft, 5Ft, and 6Ft models, this series is engineered for tractors ranging from 30 HP to 50 HP and above. It features a robust gear-driven transmission system and is constructed with durable structural components to handle demanding soil conditions.

Superior Working Depth: Offers a maximum working depth of 203/8 mm/inch across all models for deeper soil penetration.

Heavy-Duty Durability: Reinforced with durable brackets and a durable top frame to ensure a long operational life.

Flexible Performance: Multi-speed gearbox and dual RPM input (540/1000) allow for precise adjustments based on soil type and tractor power.

Enhanced Safety: Integrated shear bolt systems in both the driveline and PTO shaft protect the machine and tractor from sudden overloads.

Gearbox: Available in Single Speed and Multi Speed Gearbox options.

Blades: ""L"" type and ""C"" type blades with Curved/Square standard tine construction.

Transmission: Gear Drive transmission type.

Safety: Driveline safety device with a Shear Bolt and a PTO Shaft with Shear Bolt.

Build Components: Includes Durable Brackets and a ""Durable Top Most"" structural frame.

RPM Input: 540 / 1000.

Rotor Specifications: 89/3.5 mm/inch Rotor Tube Diameter and 480/18.9 mm/inch Rotor Swing Diameter.
