Super Plus Series

The Super Plus Series is a versatile and heavy-duty agricultural rotavator line designed for high performance across various tractor ranges. Available in sizes from 3Ft to 7Ft, these models feature a gear-driven transmission and are equipped with a heavy-duty gearbox to handle intense farming tasks. The series offers multiple configurations for blades and gearbox speeds to suit different soil requirements.

Broad Compatibility: Fits a wide range of tractors, from 24 HP to 50 HP and above.

Customizable Operations: Offers both L-type and C-type blades and multi-speed gearbox options to adapt to various land types.

Heavy-Duty Performance: Features a heavy-duty gearbox and specialized PTO shaft with shear bolt protection for long-lasting reliability.

Wide Coverage: Available in multiple widths (1210mm to 2259mm) to maximize productivity per pass.

Gearbox: Multi Speed and Single Speed options; includes a Heavy Duty Gear Box.

Blades: "L" type and "C" type blades with Curved/Square standard tine construction.

Transmission: Gear Drive transmission type.

PTO Shaft: Equipped with a PTO Shaft with Shear Bolt for safety.

RPM Input: 540 / 1000.

Safety: Driveline safety device utilizing a Shear Bolt.

Rotor Build: Rotor tube diameters ranging from 73mm to 89mm and swing diameters up to 480mm.
