MB Plough

The MB Plough is a high-performance agricultural implement designed for efficient soil inversion and deep tillage. This series features a 2-furrow configuration with a robust 100 mm x 25 mm box frame. Available in multiple models ranging from 2FHL 360-10 to 2FHM 480-10, it is engineered to handle various soil types, from soft to hard soil, depending on the specific model chosen.

Soil Versatility: Different models are optimized for specific soil conditions, including Soft Soil, Medium Soil, and Hard Soil.

Precision Control: The hydraulic adjustment system allows for easier handling and better control over the ploughing depth and alignment.

Robust Construction: High-grade bearings (32215-33017 / 33017-33019) and thick shovels (up to 38 mm X 25 mm) ensure durability in demanding conditions.

Optimized Power Matching: Compatible with a wide range of tractors, starting from 35 hp up to 50 hp.

Frame & Shaft: Built with a 100 mm X 25 mm Box frame and a main shaft ranging from 85 mm to 95 mm Round.

Tyne & Blade: Features 28 mm to 30 mm (c-type) tynes and 10 mm to 12 mm blades.

Adjustment: Equipped with a Hydraulic adjustment system for precise operation.

Mould Board: Specifically designed mould boards (up to 731-10 mm) to suit 13"" and 14"" tyre requirements.

Working Depth: Capable of a depth of cut between 10 to 14 inches.

Working Width: Offers tilling widths of 20 inches to 22 inches.
